Analysis of
Welded
Connection
Tensile Loads on Concentric Welded
Connection Members & Balanced Weld Group
About This Project
The Weld Connection Calculator features two comprehensive analysis modes following NSCP 2015 Section 510 and Besavilla's Simplified Steel Design methodology using the Allowable Stress Design (ASD) approach.
Part I: Tensile Load Analysis evaluates angle steel connections by comparing three critical limit states—Gross Area Yielding, Net Area Rupture, and Block Shear—to determine the maximum safe tensile force with governing failure mode identification.
Part II: Balanced Weld Group Analysis offers dual sub-modes: Check Design calculates connection capacity from given weld lengths, while Find Required Length determines minimum weld length needed for applied loads. Both modes include automatic weld size validation and failure mode analysis.
Key Features
- Part I: Three limit states analysis (Gross Area, Net Area, Block Shear)
- Part II: Check Design mode for capacity evaluation
- Part II: Find Required Length mode for weld sizing
- Automatic weld size validation per NSCP 2015 Table 510-4
- Real-time calculations with governing failure mode identification
Academic Project
Developed by
Sarah Jane Bualoy
Bicol University
College of Engineering
Class of 2025
Built With
Professional Weld Connection Analysis
Dual-mode calculator: Tensile Load Analysis for angle steel connections and Balanced Weld Group Analysis for design verification and sizing
NSCP 2015 Compliant
Calculations based on NSCP 2015 Section 510 and Besavilla's Simplified Steel Design methodology.
Dual Analysis Modes
Part I analyzes angle steel tensile capacity through three limit states. Part II offers Check Design for capacity verification and Find Required Length for weld sizing.
Comprehensive Analysis
Evaluates weld shear rupture, base metal yielding, and plate shear capacity. Includes automatic weld size validation and identifies the governing failure mode for safe design.
